Alert operations to plugged impulse lines
Plugged impulse lines can trap pressure and isolate the transmitter from the process. This leaves the transmitter unresponsive to pressure changes. This issue can easily remain hidden since transmitter output may continue to appear normal.
The Rosemount™ 3051 with the Plugged Impulse Line diagnostic helps ensure that your transmitter output responds to process changes. It notifies you to issues that may affect process readings before they impact process operations or safety.
How it works
• Continuously monitor for plugging in impulse lines that may disrupt output response to process changes
• Simple configuration options enable easy setup
• Safety certified for use in your most critical applications
• The built-in diagnostic log tracks events, so you see a history of the device status to diagnose intermittent issues that may occur when not connected to the device
Uncover Hidden Problems
In addition to simply providing process measurements, most instrumentation today also has some form of internal device diagnostics. However, potential points of failure still exist beyond the transmitter in the electrical loop and the process itself. Left unidentified, these issues can lead to increased maintenance costs, process upsets or shutdowns, or even compromised safety.
Detect Issue Before They Affect Operations
The Rosemount™ 3051S with Advanced Diagnostics detects issues before they can affect process operations or safety. Paired with the scalable platform of the Rosemount 3051S, this diagnostic package provides valuable insight into process operation that can enable better decision making, increase efficiency, and reduce costs in a variety of applications.
• Continuously monitor for problems throughout the entire electrical loop with the Loop Integrity diagnostic
• Proactively detect abnormal conditions in the process and equipment with the Process Intelligence diagnostic
• Monitor build-up in impulse lines with the Plugged Impulse Line diagnostic
• Get insight into the health of the transmitter with time-stamped status and event logs
• Diagnostics are safety certified for use in the most critical applications
Warranty
Up to 15-year limited warranty
Rangedown
Up to 200:1
Communication Protocol
4-20 mA HART, WirelessHART®, FOUNDATION fieldbus
Measurement Range
Up to 10000psi (689,47 bar) Gage, Up to 10000psia (689,47 bar) Absolute
Process Wetted Material
316L SST, Alloy C-276
Diagnostics
Basic Diagnostics, Loop Integrity, Process Intelligence, Plugged Impulse Line
Certifications/Approvals
SIL 2/3 certified to IEC 61508 by an independent 3rd party, NSF, NACE, hazardous location, see full specs for complete list of certifications
Features
- No-equal, scalable architecture optimizes performance, functionality and process connections
- Designed with direct threaded connections or manifolds and remote seals for a quick and cost-effective installation
- Ultra and Classic Performance class enhances process control
- 15-year stability and 200:1 rangedown produce reliable measurements and wide application flexibility
- Piezoresistive sensor technology allows calibrated spans from 0.3 to 10000 psi (20.7 mbar to 689 bar)
- Seamless integration with 4-20 mA HART®, WirelessHART®, FOUNDATION™ fieldbus protocols for application adaptability
- SIL 2/3 certified to IEC 61508 by a 3rd party and prior-use certificate of FMEDA data for safety installations
- Advanced diagnostics offer diagnostic coverage to detect electrical loop issues and abnormal process conditions
- Remote display offers easy access to device display and loop connection
