Obtain reliable temperature measurements to help improve the control of your process and avoid operational uncertainty
Temperature is the most measured variable in chemical plants, with each additional monitoring helping to increase visibility into your operations. Boost your operation’s performance through enhanced process quality, reliability, energy efficiency, and safety by deploying supplemental wireless temperature solutions from Emerson.
Input
Single sensor capability with universal sensor inputs (RTD, T/C, mV, ohms)
Output Signal
WirelessHART® protocol
Housing
Field mount
Display/Interface
Large LCD display
Diagnostics
Basic diagnostics including open/short sensor diagnostics
Calibration Options
Transmitter-sensor matching (Callendar-Van Dusen constants), 5-point calibration
Certifications/Approvals
Hazardous location, marine type, see full specs for a complete list of certifications
Update Rate
1 sec. to 60 min., user selectable
Power Module Life
Up to 10-year life, field replaceable (order separately)
Antenna Type
Internal
Features
- WirelessHART® technology is secure, cost-effective and delivers >99% data reliability
- Designed with an internal antenna for a compact and lightweight design
- Durable polymer housing offers superior resistance to process environments
- LCD displays process variables, units, percent of range and diagnostics for increased process visibility
- SmartPower™ module provides up to 10-year maintenance-free operation and field replacement without transmitter removal
- Easy installation enables quick instrumentation of measurement points without the cost of wiring
- Device dashboards provide easy interface for simplified device configuration and diagnostic troubleshooting
