OPTITEMP TRA-P10
Resistance (RTD) temperature assembly for standard applications
- Compression fitting connection
- DIN-style based on form 2, welded multipart thermowell with straight tip
- -200…+600°C / +1112°F
-
Resistance (RTD) temperature assembly for standard applications
The OPTITEMP TRA-P10 is a plug-in RTD sensor assembly with a straight welded multipart thermowell (based on form 2). The industrial temperature assembly is suitable for temperature measurement of liquids and gases. It is designed to operate up to +600°C / +1112°F. The OPTITEMP TRA-P10 can be used in pipes and tanks, at low to medium pressures and flow velocities. It is very flexible to use since the decision as to the required insertion depth is only necessary immediately prior to installation. The RTD is available with ATEX and IECEx approvals.
For standard applications
Standard: OPTITEMP TRA-P10
EX: OPTITEMP TRA-P10 Ex
Temperature
Resistance (RTD)
Liquids, Gases
Yes
DIN-style
Multipart welded
Form 2
Plug-in
Yes
Replaceable spring loaded mineral isolated measuring insert OPTITEMP TR 100
1 x Pt100, 2 x Pt100
2-wire, 3-wire, 4-wire
1/10 DIN B, A, AA, B
Ceramic terminal block, Flying wires, Temperature transmitter
Ø9 mm / 0.35″, Ø10 mm / 0.39″, Ø11 mm / 0.43″, Ø12 mm / 0.47
Straight
Pipe, Tank
Pipe, Tank
-200…600°C/-327…1112°F
Austenitic stainless steel (1.4404/316L), Austenitic stainless steel (1.4571/316Ti)
G1/2, G3/4
1/2 NPT
ATEX, IECEx
Product features and options depend on device configuration: Contact us to make sure that your preferred functionality can be combined in one device.
