Supply / Communication
2-wire (HART/ PROFIBUS PA)
PROFINET with Ethernet-APL
Bluetooth® wireless technology
Frequency
W-Band (~80 GHz)
Accuracy
+/-1 mm (0.04 in)
Ambient temperature
-40 … +85 °C (-40 … +185 °F)
Process temperature
-196 … +450 °C (-321 … +842 °F)
Process pressure / max. overpressure limit
Vacuum…160 bar (2320 psi)
Main wetted parts
316L or PTFE (clad 316L flanges)
Process connection
Flange:
DN50 … DN150
ASME 2″ … 8″
Max. measurement distance
80 m (262 ft)
Communication
4…20 mA HART
Additional analog or switch output
PROFIBUS PA
PROFINET with Ethernet-APL
Bluetooth® wireless
technology and app (optional)
Certificates / Approvals
IEC Ex, ATEX, CSA C/US, EAC Ex, JPN Ex, KC Ex,
INMETRO Ex, NEPSI Ex, UK Ex
Safety approvals
Overfill protection WHG;
SIL 2/ SIL 3
Design approvals
Acceptance test certificate 3.1, EN10204;
NACE MR0175 / ISO 15156;
NACE MR0103 / ISO 17945;
Declaration of Conformity ASME B31.3;
Conformity to cGMP;
AD2000;
PMI test;
CRN approval;
Helium leak test;
Liquid penetrant test AD2000-HP5-3(PT);
Liquid penetrant testing ISO23277-1 (PT);
Liquid penetrant testing ASME VIII-1 (PT);
Welding documentation (according to ISO or ASME)
Hygienic approvals
EU Food Contact Material (EC) 1935/2004;
US Food Contact Material FDA CFR 21
Marine approval
ABS, LR, BV, RINA, DNV
Options
Display,
Customized settings,
App ‘SmartBlue‘ for commissioning and operation via Bluetooth
Gas-tight implementation;
Overvoltage protection;
PWIS free
Application limits
Strong turbulences and foam,
long stilling wells (>12 m) and bypass -> FMR5x,FMP5x
