The solution for the following application areas:
Water purification
- Gas sampling systems, nitrogen generators
- Burner control
- Chemical injection
- Food and beverage applications
Application
Clean, low viscosity liquids and gases
Mounting
Vertically, in line or wall mouted
Connections
1/4 to 1 in., threaded, vertical or horizontal
Flow ranges
Water flows: 1 to 3000 l/h
Flow turndown
Typically 10:1
Operating pressure
Up to 100 bar (1450 lbf/in 2 g)
Operating temperature
Up to 180 °C (356 °F)
Accuracy
Class 6
Alarms
Slot sensors, up to 2 off
Tube material and float material
Stainless steel
Features
- Designed for small‑flow measurement of both liquids and gases, especially when transparency or glass‑tube construction is not suitable (i.e., for cloudy, opaque or aggressive fluids). Armored (metal cone / stainless steel) variable area principle: the float rises in the meter tube in proportion to flow.
- Wide flow range options: water flows from about 1 → 3,000 L/h (for certain sizes)
- Typical turndown (rangeability) ~10 : 1.
- High operating pressure capability: up to about 100 bar in certain versions.
- Operating temperature (measuring medium) up to around +180 °C (depending on gasket / material options) 1
- Materials: Wetted parts in stainless steel (1.4571/316Ti), O‑rings in materials such as Viton®, Buna N®, Kalrez®, EPDM.
- Indicator options: Mechanical pointer scale, optional alarm units (min or max or both), optional analog output (e.g., 4‑20 mA) with electronic converter.
- Mounting: Can be pipeline mounted vertically or wall mounted; connections from ¼″ to 1″ threaded typical.
- Suitable for applications in e.g. water purification systems, gas sampling systems, burner control, chemical injection, food & beverage processing, and more.
